Additional Product Information
Description
Specifications
| SKU | 967193401 |
|---|---|
| MANUFACTURER | Husqvarna |
| WEIGHT | 2.6kg - 5kg |
| ENGINE CAPACITY | 0cc - 29cc |
| ENGINE TYPE | 2-Stroke |
Features
Intuitive controls
The choke and purge are easy to reach and understand.
J-handle
Equipped with J-handle for greater versatility.
Standard single harness
Standard harness for lighter brushcutters
Fuel pump
Fuel pump designed for easy starting.
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%.
Auto return stop switch
When the machine is turned off, the stop button automatically returns to start position for trouble free start.
Grass bevel gear
Bevel gear designed with high torque and the cutting equipment parallell to the ground for best cutting performance
Tap 'n Go
Heavy duty twin line cutting system with Tap 'n Go for quick line feed.
Technical Data
Engine
Power output
0.6 kW
Cylinder displacement
27.6 cm³
Maximum rpm output shaft
7200 rpm
Maximum power speed
8000 rpm
Idling speed
2800 rpm
Clutch engagement speed (±120)
4200 rpm
Fuel tank volume
0.343 l
Fuel consumption
604 g/kWh
Output shaft thread
M10x1.25V
Spark plug
NGK CMR6A
Electrode gap
0.5 mm
Transmission
Drive gear angle
30 °
Dimensions
Weight (excl. cutting equipment)
4.76 kg
Tube diameter
25.4 mm
Equipment
OEM Grass blade
Grass 255-4
OEM Harness
Single harness
OEM Trimmer head
T25 (L)
Sound and Noise
Sound power level, guaranteed (LWA)
114 dB(A)
Sound power level, measured
106 dB(A)
Sound pressure level at operators ear
94 dB(A)
