Description
Specification
| SKU | 966629004 |
|---|---|
| MANUFACTURER | Husqvarna |
| WEIGHT | 7.1kg + |
| ENGINE CAPACITY | 50cc - 59cc |
| ENGINE TYPE | 2-Stroke |
Features
Adjustable handle bar
Adjustable and ergonomically designed handlebar for best comfort.
X-Torq® engine
The X-Torq® engine design increases torque over a wider rpm range providing maximum cutting power.
Long shaft
Long shaft providing extended reach, facilitating grass clearing.
Balance XT
Ergonomic harness with broad back support, shoulder straps and hip belt that distributes the load over a larger area. Adjustable back plate for perfect fit.
High offset post
High offset post increases freedom of movement when working on slopes.
Fuel pump
Fuel pump designed for easy starting.
Optimised shaft & gear
Optimised shaft length and 35 degree bevel gear facilitates operation and allows the cutting equipment working parallel to the ground.
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%.
Auto return stop switch
When the machine is turned off, the stop button automatically returns to start position for trouble free start.
Ergonomic design
Angled handle bar and comfort handles provides excellent grip and working position.
Easy switch of cutting equipment
Magnetic locking pin holder facilitates switch of cutting equipment.
LowVib®
Effective anti-vibration dampeners absorb vibration, sparing the user’s arms and hands.
Grass bevel gear
Bevel gear designed with high torque and the cutting equipment parallell to the ground for best cutting performance
Adjustable harness hook eyelet
Adjustable eye let for best balance
Ergonomic handle
Comfortable handle design.
Soft grip handles
/features/m110-03xx/m110-0352b.ashx)
Soft grip handles for comfortable use
Tap 'n Go
Heavy duty twin line cutting system with Tap 'n Go for quick line feed.
Technical Data
| Technical data | |
|---|---|
| Engine specification | |
| Cylinder displacement | 53.3 cm³ / 3.25 cu.inch |
| Cylinder bore | 45 mm / 1.77 inch |
| Cylinder stroke | 33.5 mm / 1.32 inch |
| Power output | 2.8 kW |
| Maximum power speed | 9000 rpm |
| Fuel tank volume | 1.1 lit / 37.2 fl oz |
| Fuel consumption | 480 g/kWh |
| Fuel consumption | 1.34 kg/h / 2.95 lbs/h |
| Ignition module air gap | 0.3 mm / 0.01 " |
| Idling speed | 2800 rpm |
| Spark plug | NGK BPMR7A |
| Electrode gap | 0.5 mm / 0.02 " |
| Clutch engagement speed | 4100 rpm (±120 rpm) |
| Lubricant type | Husqvarna 2 stroke or equiv. at 50:1 |
| Maximum rpm output shaft | 10500 rpm |
| Output shaft thread | M12x1.75V |
| Lubricants | |
| Lubricant type (bevel gear) | Biodegradable grease |
| Vibration & noise data | |
| Equivalent vibration level (ahv, eq) front / rear handle | 1.5/1.6 m/s² |
| Equivalent vibration level (ahv, eq) left / right handle | 1.5/1.6 m/s² |
| Sound pressure level at operators ear | 101 dB(A) |
| Sound power level, guaranteed (LWA) | 121 dB(A) |
| Transmission data | |
| Gear ratio | 1:1.47 |
| Drive gear angle | 35 ° |
| Equipment | |
| OEM Trimmer head | T55X M12 |
| OEM Grass blade | Multi 350-3 |
| OEM Harness | Balance XT |
| Overall dimensions | |
| Weight (excl. cutting equipment) | 9.2 kg / 20.44 lbs |
| Tube length | 1483 mm / 58.39 inch |
| Tube diameter | 35 mm / 1.38 " |
